Description
When aimed properly, the Spot and Combo beams comply with SAE J581 standards for an for auxiliary high beam. If you're looking for a high-performance street-legal LED pod to use as a fog light, both the NCS and HXB Wide beam models are SAE J583 compliant for use as a street legal fog light. Some localities require auxiliary lights to be covered for everyday driving. To comply, the optional Blackout Covers are designed to fit all Morimoto 4Banger LED Pods, and are a friction + clip fit that installs with ease, and can be removed in seconds.
The Morimoto 4Banger LED Pods have been developed from the ground up to set a new standard in their segment, and the same goes for the optional wire harness. If you want the best, bingo. Not one component on the harness was overlooked for the sake of cost or simplicity. Triple sealed proprietary 4-pin relay with hanger. Proprietary over-molded inline fuse holder with 20A mini fuse. DT06-2S female outputs with dual seals. Stainless steel power and ground terminals. Proprietary M-Spec push button switch with Yellow-LED backlight.
-
NOTE: These specifications are per pod / each!
-
INTENSITY (WHITE): 170,000 Cd (Post Warm-Up) (1,700lux @ 10m)
-
INTENSITY (YELLOW): 119,000 Cd (Post Warm-Up) (1190lux @ 10m)
-
INPUT: Proprietary Overmolded Deutsch DT 2-Pin
-
POWER (STABILIZED): 42w
-
CURRENT: 3.2A @ 13.5V DC
-
PEAK LUMINOSITY (RAW): 3,000lm
-
DIMENSIONS: 82mm W, 67mm H, 60mm D
-
HARDWARE: M6 x 1.0 x 8mm (4Banger to U-Bracket), M10 x 1.5 x 20mm (U-Bracket base)
-
COLOR: 2700K (Yellow) or 5700K (White)
-
LIGHT SOURCE: 3x Osram HX Boost (5700K)
-
MATERIAL: Makrolon LED PC (Lens), Powdercoated Die Cast Aluminum Housing
INCLUDED:
-
LED PODS: 2x (One Pair) Morimoto 4Banger HXB Spot (White or Yellow)
-
BRACKETS: 2x (One Pair) Universal U-Shape Mounts
-
HARDWARE: Complete pack (stainless steel)
-
OPTIONAL WIRING: 1x Morimoto 4Banger Switched Relay Harness or DT Connectors
